M1080B
Small and medium precise centerless grinding machines
Small and medium precise centerless grinding machines
80
Grinding diameter(mm)
P500×150×305
Grinding wheel diameter(mm)
PSA300×150×127
Regulating wheel diameter(mm)
0.0025
Minimum feed amount(mm)
property
Features：
Through feed：Grinding of various cylindrical parts,ring parts and long bars.
Plunge-in:Grinding of cones with a cone less than 1:20 and various shaped rotating parts.
Numerical control systems and software
SIEMENS数控系统
西门子
FANUC数控系统
发那科
MITSUBISHI数控系统
三菱
Film
Specification parameter
Product model
M1080B
Plunge-feed
Grinding diameter
5-80mm
Max length
140mm
Through-feed
Grinding diameter
5-80mm
Grinding wheel spec
P500×150×305mm
Regulating wheel spec
PSA300×150×127mm
Grinding wheel speed
1300r/min
Regulating wheel speed
10-200r/min
Regulating wheel frame swivel angle
Vertical
-2°～+5°
Horizontal
0°～+3°
Feed/Division
0.0025mm
Height from centerline of gri.wheel & reg.wheel to workrest
210mm
Total power
Grinding wheel motor
15KW
Regulating wheel motor
1.5KW
Power supply
3N 380V 50HZ
Machine dimension(L×W×H)
1950×1580×1485mm
Machine weight
About 3500Kg
Accuracy (standard bars)
Roundness
0.002mm
Cylindricity
0.003mm
Roughness
Ra0.32μm
