MK1060
Small and medium precise centerless grinding machines
Small and medium precise centerless grinding machines
60mm
Grinding diameter(mm)
P500×200(250)×305 mm
Grinding wheel diameter(mm)
PSA350×200×127 mm
Regulating wheel diameter(mm)
0.001 mm
Minimum feed amount(mm)
property
Features：
Through feed：Grinding of various cylindrical parts,ring parts and long bars.
Plunge-in:Grinding of cones with a cone less than 1:20 and various shaped rotating parts
Numerical control systems and software
SIEMENS数控系统
西门子
FANUC数控系统
发那科
MITSUBISHI数控系统
三菱
Film
Specification parameter
Product model
MK1060
Plunge-feed
Grinding diameter
5-60mm
Through-feed
Grinding diameter
5-60mm
Grinding wheel spec
P500×200（250）×305mm
Regulating wheel spec
PSA350×200×127mm
Grinding wheel speed
1318r/min
Regulating wheel speed
10-200r/min
Regulating wheel frame swivel angle
Vertical
-1°～+5°
Horizontal
0°～+5°
Regulating wheel min feed amount
0.001mm
Grinding wheel dresser min feed amount
0.001mm
Height from centerline of gri.wheel & reg.wheel to workrest
250mm
Total power
Grinding wheel motor
15KW
Regulating wheel motor
1.5KW
Power supply
3N 380V 50HZ
Machine dimension(L×W×H)
2050×1680×1380mm
Machine weight
About 3200Kg
Accuracy (standard bars)
Roundness
0.001mm
Cylindricity
0.002mm
Roughness
Ra0.16μm
